Putting a ceiling fan where an old light used to hang
Quick answer
A ceiling fan needs a fan-rated box tied into the framing. Most original ceiling boxes in older Alhambra homes were built only for a light, so we replace or brace the box first, then hang and balance the fan.
Summer afternoons in Alhambra get hot, and many older homes were never built with ceiling fans in mind. The ceiling box above your dining or bedroom light was likely sized for a fixture that weighs a few pounds. A fan weighs more, and it moves, which puts a twisting, wobbling load on that box every time it spins.
That is why the box matters more than the fan.
Why a light box is not enough
Light-only boxes are often small, shallow and held up by a couple of nails or a thin metal strap. A spinning fan can loosen that over time, leading to a wobble, a buzz, or in the worst case a fan pulling down out of the ceiling.
A fan-rated box is marked for fan support and is fastened to a joist or to a brace that spans between joists. Many can be installed through the existing hole without opening the ceiling, which matters in plaster ceilings.
Plaster ceilings need extra care
Most 1920s Alhambra homes have plaster on wood lath overhead. Plaster cracks easily when you pry or cut around it.
Choosing the right fan
- Ceiling height. Older homes often have tall ceilings, so a short downrod helps the fan move air where you are.
- Blade span. Match the fan to the room; an oversize fan in a small bedroom feels like a wind tunnel.
- Style. Bronze and wood finishes suit Spanish Revival rooms better than bright chrome.
- Light kit. If the room depends on that ceiling light, pick a fan with a good light kit.
Switch options
Many older rooms have one wall switch for the ceiling. Options include using the pull chains, a fan with a remote, or a wall control that handles fan and light separately. Adding a second switch leg through plaster walls is possible but is a bigger job; a remote is often the cleaner answer.
What makes a box fan-rated
A ceiling fan weighs more than most light fixtures and vibrates as it spins. Electrical code requires a fan to hang from a box listed for fan support, usually marked inside the box. Many older Alhambra homes have shallow pancake boxes or small boxes held only by nails or a bar never meant for a moving load. Hanging a fan on one risks the fan working loose.
Retrofit fan braces
A fan brace bar is designed for existing ceilings. It slides through the hole of the old box, rests on top of the ceiling, and expands between two joists by turning the bar. A box mounts to the bar.
On plaster and lath ceilings, we cut carefully around the hole so the plaster does not crack. The brace works even when the attic is not accessible.
When the attic is open
With attic access, we can screw a box to a solid wood block fastened between the joists. That is the strongest mount and lets us check the wiring at the same time.
Plaster ceilings
Plaster ceilings in 1920s homes are heavier and more brittle than drywall. Cutting a larger hole for a new box can crack the plaster around it. We use a sharp oscillating tool and support the area. The fan canopy usually hides small chips.
Old wiring
Many homes from this period had knob-and-tube wiring, and some still do. Ceiling fixtures often sit at the end of these runs. If the wiring at the box is cloth-covered and brittle, or there is no ground, we will tell you. Some fixes are simple; others call for an electrician.
Ceiling height
Spanish and Craftsman homes often have higher ceilings, sometimes 9 feet or more. A downrod lowers the fan to a good height, roughly 8 to 9 feet from the floor. Coved ceilings need a sloped ceiling adapter.
Our steps:
- Turn off power and remove the old fixture
- Check the box, wiring and ceiling
- Install a fan brace or blocking and a fan-rated box
- Mount the bracket and hang the fan
- Wire and balance the fan
See replacing light fixtures in 1920s ceilings for older ceiling boxes.
Remote controls
When a room has a single switch, a fan with a remote controls both the fan and its light. The receiver sits in the fan canopy.
What our install looks like
We shut off the breaker and confirm the circuit is dead. We remove the old fixture, check the wiring and the box, and replace it with a fan-rated box or brace. Then we assemble and hang the fan, connect it, and balance the blades so it runs quiet at every speed.
See our ceiling fan replacement page for more.
Keeping it quiet
If a fan starts to wobble, check that the blade screws and the canopy are tight, and dust the blades; uneven dust can be enough to throw them off balance.
